GPS Vehicle Tracker with CAN Bus - 4G Model - Lifetime Warranty Model with monthly payment

Brand: Quecklink

4G LTE Cat 1CANBUSBLE 5.2Accident DetectionCompactLifetime Warranty Model

Truck tachograph remote download, this CAN-Bus Lifetime Warranty Model combines fleet telematics, vehicle diagnostics and 4G live tracking without a hardware purchase. Location data, CAN-Bus values, driving behavior, geofencing, alerts and vehicle reports can be evaluated centrally.

Select tariff:

1

Free Shipping

On orders over €50

2 Year Warranty

On all devices

Support

Mon-Fri 9-18

Highlights

  • Minimum contract term: 3 months | Cancellation period: 3 months | Billing: semi-annually
  • Optimal use for vehicles with CAN bus: cars, trucks, vans, delivery vehicles, as well as agricultural and construction machinery (e.g., tractors, excavators, wheel loaders).
  • Wiring diagram: Yellow cable → ignition positive | Red cable → constant positive | Black cable → ground | CAN High & CAN Low → OBD/CAN bus port
  • Network coverage: Reliable 4G connection guaranteed in over 100 countries.

Features

Target group & application areas

  • •The CAN bus GPS tracker is particularly suitable where classic tracking solutions reach their limits.
  • •Fleet operators focusing on complete vehicle diagnostics
  • •Logistics and transport companies with heterogeneous fleets
  • •Vehicle owners with increased security and analysis needs
  • •Companies looking to integrate vehicle data into existing telematics platforms

Fields of application

  • •Telematics insurance tariffs (Pay-how-you-drive, UBI)
  • •Fleet management with CAN-bus-supported vehicle analysis
  • •Precise accident documentation and event analysis
  • •Recording of operating hours and mileage

Cellular & data transmission

  • •LTE Cat 1: B1/B2/B3/B4/B5/B7/B8/B20/B28 frequency bands
  • •Up to 10 Mbps downlink / 5 Mbps uplink
  • •GSM Quad-Band: 850/900/1800/1900 MHz
  • •GPRS: 85.6 Kbps, EDGE: 236.8 Kbps
  • •Internal cellular antenna for compact installation

Positioning & accuracy

  • •GNSS receiver supporting GPS, GLONASS, Galileo, BeiDou
  • •High accuracy: typical deviation < 2.0 meters (CEP)
  • •Outstanding sensitivity: -165 dBm for tracking and navigation
  • •Fast acquisition times: Hot start < 1 second

CAN bus functionality

  • •Simultaneous reading of various CAN bus systems (depends on vehicle make and model)
  • •Recording of fuel level, RPM, engine temperature, and mileage
  • •Decoding of error codes (DTCs) and dashboard warning lights
  • •Virtual ignition detection without additional wiring

Driver monitoring & safety

  • •Detailed driving behavior analysis (acceleration, braking, cornering)
  • •Accident detection with highly detailed data logging prior to the crash
  • •Towing notification triggered by the 3-axis accelerometer
  • •Over-speeding alerts and monitoring

Interfaces & connectivity

  • •Bluetooth Next Gen (BLE 5.2) for connecting wireless accessories
  • •Compatible with BLE temperature, humidity, and magnetic sensors
  • •1-Wire support for iButton/RFID and temperature probes

Geo-fencing & security zones

  • •Configuration of up to 20 individual geo-fences
  • •Immediate alerts when crossing defined boundaries
  • •Jamming detection against GPS blockers
  • •Warning for low vehicle or backup battery voltage

Configuration & management

  • •Micro-USB port for local configuration and diagnostics
  • •FOTA (Firmware Over-The-Air) for seamless remote updates
  • •Adjustable settings via SMS commands
  • •Intelligent LED indicators showing status of GNSS, cellular, and power

Power supply & design

  • •Wide operating voltage support (8–32 V DC) for 12V and 24V systems
  • •Built-in 60 mAh lithium polymer backup battery
  • •Ultra-lightweight: only 41 grams
  • •Operating temperature: -20 °C to +60 °C

Why choose the CAN bus tracker?

  • •Transforms regular vehicles into highly connected smart fleets
  • •Reduces maintenance costs through early detection of vehicle errors
  • •Increases overall fleet safety and security
  • •Future-proof hardware utilizing reliable 4G technology
